Patent: MS04G
Different from the ordinary tripod turnstile, Fingerprint Turnstile MS04G has a unique and innovative design. Black or gold titanium material makes it look more upscale and fashionable, and seamless waterproof design ensures it suitable both for indoor &
share:
Advantages Specifications Dimension Options Gallery


Fingerprint Turnstile Description

Combined with one of the most popular biometric technologies today--Fingerprint scanner, the MS04G fingerprint turnstile subverts the stereotype of the tripod turnstile, and it is no longer just a simple and boring access control device. The front and rear of the machine's shell can used with more distinctive black, rose gold or gold titanium alloy plates. Heavy-duty construction and durable, low-maintenance movement allow it to perform well in any environment. The rounded corners and seamless chassis make customers feel more comfortable.

Fingerprint Turnstile Variations:

Providing a unique and innovative image for better integration with the building, front and rear panels are made of black, rose gold, or classic gold titanium.
Standard delivery is semi-automatic type, and fully automatic (motor-driven) driving mode is also available for meeting stricter access requirements.
The fingerprint recognition system can also be replaced with a face recognition system, a barcode recognition system, or an RFID card system, depending on your own needs.

Fingerprint Turnstile Applications:

Fingerprint turnstile MS04G is always the first choice when people need enhanced security controls for their building entry and exit points, while seeking an innovative design that stands out from traditional units, such as offices, apartments, hotels, gyms, swimming pools, and sports centers.

Fingerprint Turnstile Features:


The whole system runs smoothly, low noise, no mechanical impact;

One person pass at a time,ensures no tailgating;

Automatic reset function: tripod arm will lock automatically if nobody enter within 5s(Can be set);


Tripod Arms run smoothly with low noise system;

Automatically drop arm if power fails

Can be integrated with any type of access control systems;

Simple installation, operation and maintenance;
Model No. MS04G
Cabinet Material SUS304/316 stainless steel
Arm Material SUS304/316 stainless steel
Unit Dimension(W*L*H) 1200*280*980mm
Passing Direction Uni-directional/Bi-directional
Photoelectric Sensor None
Passage Width 550mm
Opening/Closing 0.5 seconds
Flow Rate 30-35 person/min
Mechanism

Absorption of electromagnet/Motor

Power Supply AC100-230V,50Hz
Voltage from the AC (100–240) V, 50/60 Hz
from a DC source 24 V
Application Indoor and outdoor(Shelter)
Working Temperature -25℃~+70℃
Operation Humidity 0 ~ 95% (No freeze)
MCBF 8,000,000 cycles
Anti-panic mode Automatically open when power off
Communication Dry contact, Relay signal, RS485
Fingerprint Turnstile Tripod Turnstile dimension
Flexible configurations available optionally up on request.

01 Cabinet Material
Generally cabinets are made from brushed 304 stainless steel.
The following materials are also available:
02 Cabinet Anti-fingerprint process
Anti-fingerprint steel treatment is based on the original 304 stainless steel, after vacuum coating, forming a layer of bright protective film on the surface also has the function of anti-fingerprint.
03 Cabinet Colors
In addition to the primary color of stainless steel, you can also choose other colors, such as white, black, brown, etc., to make it more coordinated with your building.
04 Glass Etching
Support personalize glass barriers and side panels with etched artwork, logos or directions.
05 Panels Material
You can select plexi-glass or tempered glass for swing panels and/or filter panels.
06 Mechanism
Configured absorption of electromagnet by default.
You can choose to upgrade it with motor.
07 Custom Illumination
Besides regular LED indicator, static or dynamic lightings hidden in the glass panels are also optional ,which meets the different needs of various occasions.
*More options and customizations available on request.
