Patent: MS06B
Supermarket Swing Gate( P Gate) MS06B provides an extra-wide passageway in a minimalist design when the installation space is insufficient. With the widest passageway which reach to 1.2 meters, it is highly suitable for shopping trolleys & baby strollers
share:
Advantages Specifications Dimension Options Gallery

Supermarket Swing Gate Description:

The primary function of the supermarket swing gate is to restrict the flow of shopping people rather than fully-enclosed security. It is usually set to one-way traffic in order to distinguish the entrance and the exit to achieve the purpose of people diversion. Due to its small footprint and simple operation, it is easy to integrate with other safety accessories, providing greater functionality and cost-effectiveness.The expandable aisle width provides suitable passage space for various users.

Supermarket Swing Gate Variations:

Swing arms can be made from stainless steel or acrylic. Stainless steel is often used for outdoor or access for trolleys and bicycles. In the event of a crash, the swing arm won't deform or break due to the sturdy material. Acrylic is often used in places where beauty is more desired.
According to the required aisle width, a single unit can be used independently, or two units can be combined to form a wider aisle.

Supermarket Swing Gate Applications:

Favorable cost, easy installation and extremely low maintenance, so MS06B supermarket turnstiles are not only used in supermarkets, such as warehouse entrances, office reception desks, hotel lobby registration, control points of each floor and many more places.

Supermarket Swing Gate Features:


Photoelectric sensors detect including unauthorized entry, tailgating , illegal intrusion, reverse intrusion, etc;

Automatic reset functio;n: swing arms will lock automatically if nobody enter within 5s(Can be set);

Passage width from 500-1100mm,suitable for disabled and trolley access;

Swing barriers run smoothly with lose noise system;

With anti-collision movement, swing barriers will reset automatically if they are strong hit by bicycle or trolley;

Can be integrated with any type of access control systems;

Simple installation, operation and maintenance;
Model No. MS06B
Cabinet Material SUS304/316 stainless steel
Swing Material stainless steel or Plexi-glass
Unit Dimension(W*L*H) 168*980mm
Passing Direction Uni-directional/Bi-directional
Photoelectric Sensor None
Passage Width 500-1100mm
Opening/Closing 0.6 seconds
Flow Rate 40-45 person/min
Mechanism Brushl motor
Power Supply AC100-230V,50Hz
Voltage from the AC (100–240) V, 50/60 Hz
from a DC source 24 V
Application Indoor and outdoor(Shelter)
Working Temperature -25℃~+70℃
Operation Humidity 0 ~ 95% (No freeze)
MCBF 5,000,000 cycles
Anti-panic mode Automatically open when power off
Communication Dry contact, Relay signal, RS485
Flexible configurations available optionally up on request.
01 Cabinet Material
Generally cabinets are made from brushed 304 stainless steel.
The following materials are also available:
02 Cabinet Anti-fingerprint process
Anti-fingerprint steel treatment is based on the original 304 stainless steel, after vacuum coating, forming a layer of bright protective film on the surface also has the function of anti-fingerprint.
03 Cabinet Colors
In addition to the primary color of stainless steel, you can also choose other colors, such as white, black, brown, etc., to make it more coordinated with your building.
04 Glass Etching
Support personalize glass barriers and side panels with etched artwork, logos or directions.
05 Panels Material
You can select plexi-glass or tempered glass for swing panels and/or filter panels.
06 Mechanism
Configured brushless motor by default.
You can choose to upgrade it with servo motor, make it perform even better beyond your expect.
High swing arm(ground clearance≥1.2meter) configured servo motor by default.
07 Custom Illumination
Besides regular LED indicator, static or dynamic lightings hidden in the glass panels are also optional ,which meets the different needs of various occasions.
*More options and customizations available on request.
