Patent: MS04B
Office Turnstils MS04B Speed Gate is an ultra slim speed gate combining security and comfort in a minimalist design. It is a terrific solution for  entrance points of banks, administrative buildings, business centers and other sites
Advantages Specifications Dimension Options Gallery

Office Turnstile Video:

Office Turnstile Description:

As the first point of contact for a building/company, office turnstiles have a profound impact on the image of the entire building or company by employees and visitors. The MS04B office turnstile undoubtedly plays a important and positive role here. Designed elegantly and stylishly, the turnstile becomes a building landmark instead of just a cold device.
Thanks to the industry-leading advanced technology, MS04B provides high throughput while the entire case width is less than half of the traditional case, so it appears more harmonious and coordinated visually.

Office Turnstile Installation Guide:

Office Turnstile Variations:

Taking "simple and exquisite" as the starting point of the appearance design, it is changeable in function and accessories. Office turnstile MS04B is not only compatible with various access control accessories, such as swipe card reader, QR code scanner, face recognition, etc., but also provides the most simple and intuitive operation. It can be installed in various office situations as a standard passage or a barrier-free passage for the disabled.
The top cover can be black or white marble, and many other patterns and colors are available.

Office Turnstile Applications:

As a reliable entrance system in the office, both security and comfort must be considered at the same time, and the MS04 has won everyone's love with its reliable performance and attractive appearance. In addition to offices, this model also plays an important role in cultural institutions, commercial centers, subways, administrative agencies, libraries, etc.

Office Turnstile Features:

Photoelectric sensors detect including unauthorized entry, tailgating , illegal intrusion, reverse intrusion, etc;
Ensure that children pass safely with two sensors specially for detecting them;
Automatic reset function: swing arms will lock automatically if nobody enter within 5s(Can be set);
Passage width from 600-950mm, suitable for disabled and trolley access;
Swing barriers run smoothly with low noise system;
With anti-collision movement, swing barriers will reset automatically if they are strong hit by bicycle or trolley;
Can be integrated with any type of access control system;
Simple installation, operation and maintenance;
Model No. MS04B
Cabinet Material SUS304/316 stainless steel
Swing Material Plexi-glass or tempered glass
Unit Dimension(W*L*H) 1500*120*980mm
Passing Direction Uni-directional/Bi-directional
Photoelectric Sensor 6 pairs (2 for protecting children)
Passage Width 600-950mm
Opening/Closing 0.6 seconds
Flow Rate 40-45 person/min
Mechanism Brushless motor
Power Supply AC100-230V,50Hz
Voltage from the AC (100–240) V, 50/60 Hz
from a DC source 24 V
Application Indoor and outdoor(Shelter)
Working Temperature -25℃~+70℃
Operation Humidity 0 ~ 95% (No freeze)
MCBF 8,000,000 cycles
Anti-panic mode Automatically open when power off
Communication Dry contact, Relay signal, RS485
Office Turnstile  地扪sion
Flexible configurations available optionally up on request.
01 Cabinet Material
Generally cabinets are made from brushed 304 stainless steel.
The following materials are also available:
02 Cabinet Anti-fingerprint process
Anti-fingerprint steel treatment is based on the original 304 stainless steel, after vacuum coating, forming a layer of bright protective film on the surface also has the function of anti-fingerprint.
03 Cabinet Colors
In addition to the primary color of stainless steel, you can also choose other colors, such as white, black, brown, etc., to make it more coordinated with your building.
04 Glass Etching
Support personalize glass barriers and side panels with etched artwork, logos or directions.
05 Panels Material
You can select plexi-glass or tempered glass for swing panels and/or filter panels.
06 Mechanism
Configured brushless motor by default.
You can choose to upgrade it with servo motor, make it perform even better beyond your expect.
High swing arm(ground clearance≥1.2meter) configured servo motor by default.
07 Custom Illumination
Besides regular LED indicator, static or dynamic lightings hidden in the glass panels are also optional ,which meets the different needs of various occasions.
*More options and customizations available on request.
