Patent: MS03B
Swing Turnstile MS03B  is durable and afforable with precision and rainproof design. people always give preference to it when outdoor turnstiles are needed. This unit is fully customisable and can be tailored to complement your design
Advantages Specifications Dimension Options Gallery

Swing Turnstile Video:

Swing Turnstile Description:

Polished 304 stainless steel housing, brushless anti-collision control system, industry-leading components, and user-friendly operation, the MS03B is one of the most cost-effective. Versatile parameter settings allow them to provide companies with high-level, customized and targeted security controls.
The whole machine has a streamlined and seamless design, and the waterproof and dustproof grade is up to IP65, so that the MS03B can perform perfectly indoors and outdoors.

Swing Turnstile Variations:

Swing Turnstile Variations:

Available in powder coat finish in more colour options;
Provides regular 600mm passage, 900mm widened passage which is accessible for people in wheelchairs or baby in spam;
The material of the swing arm can also choose stainless steel or plexiglass;

Swing Turnstile Applications:

In the past, people often saw swing turnstiles indoors, such as offices, hotels or hospitals. But in fact, some outdoor occasions, such as factories, factories, schools, parks, scenic spots, etc., are also very eager to manage the access of employees and visitors intelligently. Swing turnstile MS03B is one of their best options, as it offers the highest cost-effectiveness as well as management efficiency even in demanding outdoor conditions.

Swing Turnstile Features:

Photoelectric sensors detects including unauthorized entry, tailgating , illegal intrusion, reverse intrusion, etc;
Ensure that children pass safely with two of sensors specially for detecting them;
Automatic reset function: swing arms will lock automatically if nobody enter within 5s(Can be set);
Passage width from 600-900mm,suitable for disabled and trolley access;
Swing barriers run smoothly with lose noise system;
With anti-collision movement, swing barriers will reset automatically if they are strong hit by bicycle or trolley;
Can be integrated with any type of access control systems;
Simple installation, operation and maintenance;
Model No. MS03B
Cabinet Material SUS304/316 stainless steel
Swing Material Plexi-glass or tempered glass
Unit Dimension(W*L*H) 1400*200*980mm
Passing Direction Uni-directional/Bi-directional
Photoelectric Sensor 5 pairs (2 for protecting children)
Passage Width 600-900mm
Opening/Closing 0.6 seconds
Flow Rate 40-45 person/min
Mechanism Brushless motor
Power Supply AC100-230V,50Hz
Voltage from the AC (100–240) V, 50/60 Hz
from a DC source 24 V
Application Indoor and outdoor(Shelter)
Working Temperature -25℃~+70℃
Operation Humidity 0 ~ 95% (No freeze)
MCBF 8,000,000 cycles
Anti-panic mode Automatically open when power off
Communication Dry contact, Relay signal, RS485
Swing Turnstile dimension
Flexible configurations available optionally up on request.
01 Cabinet Material
Generally cabinets are made from brushed 304 stainless steel.
The following materials are also available:
02 Cabinet Anti-fingerprint process
Anti-fingerprint steel treatment is based on the original 304 stainless steel, after vacuum coating, forming a layer of bright protective film on the surface also has the function of anti-fingerprint.
03 Cabinet Colors
In addition to the primary color of stainless steel, you can also choose other colors, such as white, black, brown, etc., to make it more coordinated with your building.
04 Glass Etching
Support personalize glass barriers and side panels with etched artwork, logos or directions.
05 Panels Material
You can select plexi-glass or tempered glass for swing panels and/or filter panels.
06 Mechanism
Configured brushless motor by default.
You can choose to upgrade it with servo motor, make it perform even better beyond your expect.
High swing arm(ground clearance≥1.2meter) configured servo motor by default.
07 Custom Illumination
Besides regular LED indicator, static or dynamic lightings hidden in the glass panels are also optional ,which meets the different needs of various occasions.
*More options and customizations available on request.
